23 m Modern Trawler | 23 m | €1,995,000

2019 SES Yachts 23.5m Custom M/Y IGUAZU | Original Owner | 1,500 NM Range

Main Features

Builder: SES Yachts
Year of Build: 2019
Length Overall (LOA): 23.47 m
Hull Construction: Composite (Vinyl Ester Resin)
Classification: CE Certification – Category B
Main Engines: 2 x 1,000 hp Caterpillar C12.9
Cruising Speed: 14 knots
Maximum Speed: 22 knots
Fuel Capacity: 5,000 Liters
Maximum Range: 1,500 NM
Navigation & Communication: Raymarine Suite
Guest Accommodation: 8 guests in 4 cabins
Crew Accommodation: 3 crew in 2 cabins (separated living area)
Flag: Turkey

Delivered in early 2019 by SES Yachts, M/Y IGUAZU is a 23.47-meter custom composite motor yacht designed for efficient, extended cruising. Her exterior profile, developed collaboratively by the shipyard’s in-house engineering team and Italy’s Duck Design, prioritizes functional deck spaces, clear sightlines, and safe deck circulation. Notably, the hull is constructed utilizing vinyl ester resin, a specification that provides superior structural integrity and osmotic resistance compared to conventional polyester formulations.

Internally, Barbara Pensoy’s design maximizes the available volume to create highly usable living areas suitable for long periods on board. The interior arrangement focuses on clear lines of sight and practical ergonomics. The accommodation layout is configured to sleep eight guests across four well-proportioned cabins. Circulation on board is planned with operational efficiency in mind; the crew quarters are entirely separated from the guest areas, featuring two cabins that accommodate a crew of three. This layout ensures both guest privacy and an uninterrupted professional service flow.

In the engine room, IGUAZU is equipped with twin Caterpillar C12.9 engines, each generating 1,000 horsepower. This propulsion package is specifically optimized for economic operation. The vessel cruises comfortably at 14 knots and is capable of reaching a maximum speed of 22 knots. Drawing from a 5,000-liter fuel capacity, she achieves an autonomous range of 1,500 nautical miles, making her highly capable for comprehensive Mediterranean itineraries. Navigational operations are managed via a complete Raymarine electronics suite. Operating under CE Category B certification, she is a proven, capable platform for offshore navigation.

For more info contact:

Eliad Hagiladi

eliad@yacht-marine-brokerage.com

+ 90 543 953 8678

Photo Gallery

SEND ME FULL INFO

Main Features

L.O.A.	23 m	Main Engines	2 x Caterpillar C12.9 1000 hp
Year	2019	Engine hours	700 hrs. February 2026
Shipyard	SES YACHTS, Istanbul	Generator	2 X Caterpillar 27 kw + 13 kw
Hull Material	GRP Vinyl Ester	Cruising Speed	14 knots
Guests / Cabins	8 in 4 cabins	Classification	CE

Specification List

Main Features:

LOA – 23,47 m

Year – 2019

Builder SES YACHTS

Class CE certification Category B

Guests – 8 in 4 cabins

Crew – 3 (in 2 separated living area cabins)

Main Engines – 2 X 1000hp C12.9Lt. – CAT

Cruising Speed – 14 knots

Range 1,500 NM

Flag – Turkey

Dimensions

L.O.A 23,47 m

LWL 20,80 m

Beam 6.10 m

Draft 1.4 m

Displacement 50 tons

Tankage

Fuel Capacity: 5.000 liters

Fresh Water capacity: 1500 liters

Black water tank capacity: 500 Liters

Grey water tank capacity: 500 Liters

Mechanical

Main Engines 2 X 1000 hp Caterpillar C12.9 (560 hrs. Feb 2026)

Generators Caterpillar 1 x 13kw + 1 x 27 Kw (2500 hrs. Feb 2026)

Gearbox – ZF

Rudder system-BCS

Rudder – 2 pcs stainless

Shafts – 2 pcs 70 mm (diameter to be calculated)

propeller 2 pcs 4 blades

Bow Thruster Max Power 20 hp

Stern Thrusters Max Power 20 hp

Fuel tanks and sound insulation located in the engine room compartment

2 pcs fuel filter for generators and engines

2 pcs seawater filter and valves

Exhaust system at back of boat with hull manifold

Stainless pipe system for engine water circuit

Electrohydraulic steering system for two stations

Emergency steering

Hot water – 100 liter tank

Water maker – FSM / 180 LPH

Navigation & Communication

Chart plotter Raymarine 2 X 12 “ at wheel house 1 X 12” at flybridge helm

GPS Raymarine

Radar Raymarine TX06S-1

Depth sounder 1 pcs b744V Bronze + 600w Thru Hull-depth, temp, speed Navico

VHF @ X Raymarine

AIS device

1 satellite TV antenna

Safety

For engine room; fixed CO2 fire extinguisher remote controlled.

Smoke detector, with alarm or fixed automatic exploding extinguisher

Instantaneous shut-off valves in fuel system

4 X Bilge submersible pump and float switch

1 X Bronze central bilge-fire pump

Camera room camera system (cockpit controlled)

Fireproof door

Domestic Appliances, Equipment & Laundry

Oven: Siemens

Stove: Siemens

Microwave: Siemens

Fridge/Freezer: Siemens

Freezer : Siemens

Dish washer: Siemens

Washing machine: Siemens

Icemaker: German Made

Electrical equipment

Internal equipment panel, relay, contactor for rear remote control with main panel in engine room

Batteries and switch panel

Aluminum device panel with silk screen in metal painted box

Navigation monitors with cable connection to the control panel on the bridge

Bilge alarm and walkway lamps

Junction box for each cabin

2 sets of motor instruments with –alarm and gauges (bridge and flybridge).

1pcs fuel gauge (in service tank)

1 pc water gauge

Two compasses.

Switch panel

1ad horn

Italian lighting fixture for indoor use 24 V (cabinets dimmer)

Italian lighting fixture for outdoor use 24 V

Fluorescent lighting in engine room

Marine speakers

Navigation lights – approved type

Iron lighting-approved type

Shor power – 220 V Marinco

1 pcs 100 A.or 2 pcs 80 A. Rectifier

1pcs 3000Watt Inverter

3pcs battery switch

Service batteries 6V cells Gel batteries (24V)

Engine start – 12V batteries

Generator start – 12V batteries

Galvanized central protection or copper busbar

6 X engine room fans (4 in 2 out)

3 pcs pantograph wiper on windscreen

Dining table, seating group and call system (bell, numerator) receivers from master cabin kitchen, cockpit, crew cabin (outside intercom)

Lighting Automation

Deck

Cockpit, deck and post platform teak decking (10 mm)

Electrical Passarella

Passarella remote control (outside type, crane function)

2 Kw. Vertical windlass with double dowel or 2 separate windlasses

2 X capstan

Anchor 2 X 100 kg

Anchor chains (12 mm, 2 x 110 m) Stainless locked anchor for 2ad slug hole

Stainless anchor housing.

6 X stainless bollard

Hydraulic water platform and electrical swimming ladder

swimming shower

Water and diesel filling from transom corners

Full stainless railings

U-railings on portable platform (portable)

Manual folding ladder

white LED lighting on stairs and steps in main sections

Outdoor fabric cushions

Dinghy

4.3 m NorthStar

Yamaha 60 hp
